Name: Spiral Bevel Gear Teeth Cutting Material Alloy Steel AISI 8620
Brand: YIZGEAR
Price: 300 USD

Brand Name : YIZGEAR

Model Number : SP23102505

Certification : QC

Place of Origin : CHINA

MOQ : 5 Pcs

Price : $300/ Piece

Payment Terms : L/C, T/T

Supply Ability : 500 Sets/Month

Delivery Time : 60 days

Packaging Details : Plywood Crate

Gear Type : Gleason

Working angle : 90°

Manufacture Type : Gear Milling

Gear Gridning : Yes

DP : 5

Gear Width : 125mm

Contact Now

Spiral Bevel Gear Teeth Cutting Material Alloy Steel AISI 8620

Feature of Spiral Bevel Gear

Versatility in Shaft Angles: Spiral bevel gears can accommodate a wide range of shaft angles, typically 90 degrees, making them versatile for various mechanical systems. They are commonly used in applications where intersecting shafts need to transmit power and motion at specific angles.
Efficient Power Transmission: The spiral tooth profile of these gears helps minimize friction and improve power transmission efficiency. The gradual tooth engagement reduces sliding contact between teeth, resulting in lower energy losses and increased overall efficiency.
High Precision and Accuracy: Spiral bevel gears require precise manufacturing processes to ensure proper tooth meshing, alignment, and optimal performance. Their production involves specialized machining techniques and stringent quality control measures to achieve the desired tooth geometry, dimensional accuracy, and surface finish.

Technical Specifications

Parameter	Specification
Custom Made	Available
Gear Profile Type	Gleason
Manufacturing Process	Gear Milling & Gear Teeth Grinding
Teeth Grinding	Included
Module (M)	Custom
Number of Teeth (Z)	Custom
Pressure Angle (α)	Custom
Lead Angle	Custom
Accuracy Grade	ISO 6 Grade/ AGMA 11Grade
Heat Treatment	Carburizing/Cement Quenching
Surface Hardness	58-62HRC

Steel Code Grades Comparison

CHINA/GB	ISO	ГΟСТ	ASTM	JIS	DIN
45	C45E4	45	1045	S45C	CK45
40Cr	41Cr4	40X	5140	SCr440	41Cr4
20CrMo	18CrMo4	20ХМ	4118	SCM22	25CrMo4
42CrMo	42CrMo4	38XM	4140	SCM440	42CrMo4
20CrMnTi		18XГT		SMK22
20Cr2Ni4		20X2H4A
20CrNiMo	20CrNiMo2	20XHM	8720	SNCM220	21NiCrMo2
40CrNiMoA		40XH2MA/40XHMA	4340	SNCM439	40NiCrMo6/36NiCrMo4
20CrNi2Mo	20NiCrMo7	20XH2MA	4320	SNCM420

Production Equipment

Spiral Bevel Gear Teeth Cutting Material Alloy Steel AISI 8620

Production Process

Spiral Bevel Gear Teeth Cutting Material Alloy Steel AISI 8620
